16 Pair / 32 Core Foil + Braid Shielded Balanced Audio Cable
KEY FEATURES
- 16 twisted pairs / 32 colour-coded stranded copper conductors
- Pair screening plus overall copper braid for higher EMI protection
- 18, 20, 22, 24 AWG Series options
- PVC, LSZH, PE Outdoor jacket choices
- Low-capacitance audio construction subject to released factory design
- Exact searchable ordering code for every approved combination
| AWG | 18 awg, 20 awg, 22 awg, 24 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Blue |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
Supplied in Oman by Khan Cables from our Muscat office and showroom in Ruwi, for projects in Muscat and across the Sultanate. Request a quote
Full specifications & datasheet: tmtglobal.co.uk →
Choosing the 16 Pair / 32 Core Foil + Braid Shielded Balanced Audio Cable
16 pairs make it a multicore snake: up to 16 balanced channels between stage boxes, AV racks and mixing positions in one cable. Foil plus tinned-copper braid gives the strongest protection against electrical noise and adds mechanical strength, which is why it is the usual choice in plant rooms, near VFDs and motors, and across industrial sites.
Related options in this range: 8 Pair / 16 Core Foil + Braid Shielded Balanced Audio Cable · 12 Pair / 24 Core Foil + Braid Shielded Balanced Audio Cable · 24 Pair / 48 Core Foil + Braid Shielded Balanced Audio Cable · 16 Pair / 32 Core Foil Shielded Balanced Audio Cable
Order code: 32B-AU. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT 16 Pair / 32 Core Foil + Braid Shielded Balanced Audio Cable Series
TMT Global 16 Pair / 32 Core Foil + Braid Shielded Balanced Audio Cable is a configurable balanced analogue line-level audio cable family for studios, broadcast rooms, AV racks, theatres, venues and installed sound systems. The product page fixes the 16-pair foil-plus-braid screened construction, while the TMT Series ordering table provides exact conductor-size and jacket item codes for search, quotation and project selection.
KEY FEATURES
- 16 twisted pairs / 32 colour-coded stranded copper conductors
- Pair screening plus overall copper braid for higher EMI protection
- 18, 20, 22, 24 AWG Series options
- PVC, LSZH, PE Outdoor jacket choices
- Low-capacitance audio construction subject to released factory design
- Exact searchable ordering code for every approved combination
TYPICAL APPLICATIONS
- Balanced line-level analogue audio
- Studio, broadcast and AV rack interconnection
- Mixing consoles, patch bays and signal processors
- Theatres, venues, hospitality and installed sound systems
- Multipair audio snakes and central equipment rooms
Technical Specification
AWG / NOMINAL AREA / SERIES AVAILABILITY
