TMT Global 14-Core Separable Peel OSDP Access Control Composite, black composite access-control cable with peelable/separable parallel subcables, foil-shielded OSDP data pair and separated reader/lock power groups, exactly fourteen insulated copper conductor tips.

14 Core Separable Peel OSDP Access Control Composite

KEY FEATURES

  • Access-control-specific construction
  • 1PR22 + 2C18 + 6C22 + 4C18
  • OSDP pair shielded
  • 305 m standard package
  • Factory evidence required for released electrical values
Chat with Sales
AWG22 awg
BrandTMT Global
ColourGrey
Jacket TypePVC, LSZH
Length305 m

Supplied in Oman by Khan Cables from our Muscat office and showroom in Ruwi, for projects in Muscat and across the Sultanate. Request a quote

Full specifications & datasheet: tmtglobal.co.uk →

View / Print DatasheetContact Sales
Description

TMT 14 Core Separable Peel OSDP Access Control Composite Series

TMT Global 14 Core Separable Peel OSDP Access Control Composite is a controlled Security & ELV cable family for professional door access-control installations. Separable OSDP access-control composite for a single-pull installation while retaining a true shielded RS-485 reader pair and dedicated power/auxiliary legs. Jacket and permitted conductor-size variations remain exact searchable Series rows under this product page.

KEY FEATURES

  • Access-control-specific construction
  • 1PR22 + 2C18 + 6C22 + 4C18
  • OSDP pair shielded
  • 305 m standard package
  • Factory evidence required for released electrical values

APPLICATIONS

  • OSDP door installations
  • Single-pull access cabling
  • Field-separated door circuits

Technical Specifications

AWG / NOMINAL AREA / SERIES AVAILABILITY
