TMT Global 2-Core Unshielded Control Cable, black jacket, no foil or braid, exactly two insulated stranded copper conductors in red and black, two visible tips.

2 Core Unshielded Control Cable

KEY FEATURES

  • 2-core controlled construction
  • No metallic screen
  • 12, 14, 16, 18, 20, 22, 23 and 24 AWG Series options
  • PVC, LSZH and outdoor PE jacket choices
  • Bare-copper conductor; solid or stranded by released drawing
  • Exact searchable ordering code for every standard combination
Chat with Sales
AWG12 awg, 14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 23 awg, 24 awg
BrandTMT Global
ColourBlack, Grey
Length305 m
Jacket TypePVC, LSZH, PE Outdoor
View / Print DatasheetContact Sales
Description

Choosing the 2 Core Unshielded Control Cable

Two cores suit one device: a lock, exit button, door contact or a powered sensor. No metallic screen keeps it light, flexible and quick to terminate; choose it for clean electrical environments where the route stays away from mains power and motor drives.

Related options in this range: 2-Wire Twisted Unshielded Door-Entry Bus Cable · 3 Core Unshielded Control Cable · 2-Wire Bus + 2 Core Power Composite Intercom Cable · OSDP Long-Run Reader Cable – 1 Pair 22 AWG + 2 Core 16 AWG Power · OSDP Reader Cable – 1 Pair 22 AWG + 2 Core 18 AWG Power · 2 Core Door Contact Cable

Order code: 02U-BA. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT 2 Core Unshielded Control Cable Series

TMT Global 2 Core Unshielded Control Cable is a configurable multicore control-cable family for machinery, control panels, building services and low-voltage automation interconnection. The product page fixes the 2-core unshielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.

KEY FEATURES

  • 2-core controlled construction
  • No metallic screen
  • 12, 14, 16, 18, 20, 22, 23 and 24 AWG Series options
  • PVC, LSZH and outdoor PE jacket choices
  • Bare-copper conductor; solid or stranded by released drawing
  • Exact searchable ordering code for every standard combination

TYPICAL APPLICATIONS

  • Machine and equipment control circuits
  • Control panels, switchboards and plant rooms
  • Relays, contactors, actuators and interlock circuits
  • Building automation and process-control interconnection
  • Industrial facilities, commercial buildings and infrastructure

Technical Specification

PARAMETER SPECIFICATION
Product type Multicore control cable
Core configuration 2 insulated cores
Conductor material Bare copper
Conductor construction Solid or stranded
Available conductor sizes 12 / 14 / 16 / 18 / 20 / 22 / 23 / 24 AWG
Core insulation PVC or halogen-free compound
Screening No metallic screen
Outer-jacket options PVC / LSZH / PE Outdoor
Cable form Round
Standard colours Grey for PVC/LSZH; black for PE Outdoor
Series 02U-BA SERIES
Ordering combinations 8 conductor sizes × 3 jacket options
Standard searchable SKUs 24 per family
Package length 305 m standard TMT package

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA SERIES AVAILABILITY
12 AWG 3.31 mm² PVC / LSZH / PE Outdoor • 305 m • Standard / project
14 AWG 2.08 mm² PVC / LSZH / PE Outdoor • 305 m • Standard / project
16 AWG 1.31 mm² PVC / LSZH / PE Outdoor • 305 m • Standard range
18 AWG 0.823 mm² PVC / LSZH / PE Outdoor • 305 m • Standard range
20 AWG 0.519 mm² PVC / LSZH / PE Outdoor • 305 m • Standard range
22 AWG 0.326 mm² PVC / LSZH / PE Outdoor • 305 m • Standard range
23 AWG 0.258 mm² PVC / LSZH / PE Outdoor • 305 m • Made to order
24 AWG 0.205 mm² PVC / LSZH / PE Outdoor • 305 m • Standard range
Download

visit: www.tmtglobal.co.uk

UL
BASEC
Intertek
IEC
ISO
SIRA
rohs
etisalat
DU
tmt global
tmt global
COO
Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourPackQR Code
2 Core Unshielded Control Cable02U-BA12 awgPVCGrey305 m QR code for 0212BPURG-BA
2 Core Unshielded Control Cable02U-BA12 awgLSZHGrey305 m QR code for 0212BLURG-BA
2 Core Unshielded Control Cable02U-BA12 awgPE OutdoorBlack305 m QR code for 0212BKURK-BA
2 Core Unshielded Control Cable02U-BA14 awgPVCGrey305 m QR code for 0214BPURG-BA
2 Core Unshielded Control Cable02U-BA14 awgLSZHGrey305 m QR code for 0214BLURG-BA
2 Core Unshielded Control Cable02U-BA14 awgPE OutdoorBlack305 m QR code for 0214BKURK-BA
2 Core Unshielded Control Cable02U-BA16 awgPVCGrey305 m QR code for 0216BPURG-BA
2 Core Unshielded Control Cable02U-BA16 awgLSZHGrey305 m QR code for 0216BLURG-BA
2 Core Unshielded Control Cable02U-BA16 awgPE OutdoorBlack305 m QR code for 0216BKURK-BA
2 Core Unshielded Control Cable02U-BA18 awgPVCGrey305 m QR code for 0218BPURG-BA
2 Core Unshielded Control Cable02U-BA18 awgLSZHGrey305 m QR code for 0218BLURG-BA
2 Core Unshielded Control Cable02U-BA18 awgPE OutdoorBlack305 m QR code for 0218BKURK-BA
2 Core Unshielded Control Cable02U-BA20 awgPVCGrey305 m QR code for 0220BPURG-BA
2 Core Unshielded Control Cable02U-BA20 awgLSZHGrey305 m QR code for 0220BLURG-BA
2 Core Unshielded Control Cable02U-BA20 awgPE OutdoorBlack305 m QR code for 0220BKURK-BA
2 Core Unshielded Control Cable02U-BA22 awgPVCGrey305 m QR code for 0222BPURG-BA
2 Core Unshielded Control Cable02U-BA22 awgLSZHGrey305 m QR code for 0222BLURG-BA
2 Core Unshielded Control Cable02U-BA22 awgPE OutdoorBlack305 m QR code for 0222BKURK-BA
2 Core Unshielded Control Cable02U-BA23 awgPVCGrey305 m QR code for 0223BPURG-BA
2 Core Unshielded Control Cable02U-BA23 awgLSZHGrey305 m QR code for 0223BLURG-BA
2 Core Unshielded Control Cable02U-BA23 awgPE OutdoorBlack305 m QR code for 0223BKURK-BA
2 Core Unshielded Control Cable02U-BA24 awgPVCGrey305 m QR code for 0224BPURG-BA
2 Core Unshielded Control Cable02U-BA24 awgLSZHGrey305 m QR code for 0224BLURG-BA
2 Core Unshielded Control Cable02U-BA24 awgPE OutdoorBlack305 m QR code for 0224BKURK-BA
