4 Triads (12 Core) Foil Shielded Instrumentation Cable
KEY FEATURES
- 4 Triads (12 Core) controlled twisted-triad construction
- Individually foil-screened pairs/triads plus overall foil screen and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 24 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Grey |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
Supplied in Oman by Khan Cables from our Muscat office and showroom in Ruwi, for projects in Muscat and across the Sultanate. Request a quote
Full specifications & datasheet: tmtglobal.co.uk →
Choosing the 4 Triads (12 Core) Foil Shielded Instrumentation Cable
With four individually screened triads, one run can carry four three-wire field signals such as RTD temperature sensors or three-wire transmitters back to the control system. An overall aluminium/polyester foil screen with drain wire blocks high-frequency interference, so it suits signal and data circuits that share containment with other cabling.
Related options in this range: 4 Pairs (8 Core) Foil Shielded Instrumentation Cable · 3 Triads (9 Core) Foil Shielded Instrumentation Cable · 6 Triads (18 Core) Foil Shielded Instrumentation Cable · 12 Pairs (24 Core) Foil Shielded Instrumentation Cable · 4 Triads (12 Core) Foil + Braid Shielded Instrumentation Cable · 4 Triads (12 Core) Unshielded Instrumentation Cable
Order code: T04S-MC. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT 4 Triads (12 Core) Foil Shielded Instrumentation Cable Series
TMT Global 4 Triads (12 Core) Foil Shielded Instrumentation Cable is a configurable instrumentation-cable family for analogue, digital and process-control signals between field instruments, control panels, PLC/DCS systems and monitoring equipment. The product page fixes the 4 triads (12 core) foil shielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.
KEY FEATURES
- 4 Triads (12 Core) controlled twisted-triad construction
- Individually foil-screened pairs/triads plus overall foil screen and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
TYPICAL APPLICATIONS
- 4–20 mA and 0–10 V instrumentation loops
- Process measurement, transmitters and monitoring circuits
- PLC/DCS analogue and digital I/O wiring
- RTD, valve, actuator and positioner circuits
- Industrial plants, utilities and building-services systems
Technical Specification
AWG / NOMINAL AREA MATRIX
