loop detector Gate automation Single Channel 12-24V AC tmt

TMT Global loop Detector Gate Barrier Gate Motor Single Channel 12-24V AC

TMT Global   loop Detector Gate automation Single Channel 12-24V AC tmt Loop detectors in recent years have become a popular tool having innumerable applications in policing, right from surveillance operations to traffic control. Automation of gates and doors has become a popular usage of the  loop detector.

The Digital Technology of the Loop Detector Enables the  Equipment to sense a change in the Inductance of the loop as soon as it Detects the metal object in its path. The inductive loop which detects the object is made of insulated electrical wire (32/020; 32 Strand, 2mm diameter) and is arranged either as a square or rectangle shape.

Technical Parameters

• Product Name: Loop Detector
• Self-turning range: 20-2000μH
• Response Times: Turn-on 10-90MS Turn-off 10-90MS
• Sensitivity: 16 way selectable , Highest 0.010% DL/L , Lowest 2.56% DL/L
• Power Requirements: 110-240VAC (48 to 62Hz) 12-24VADC(48 to 62Hz)
• Visual Indications: Power LED-Red,  Channel LED-Green
• Reset: Reset by push button on front of enclosure
• Frequency Four step switch selectable 20-80KHz
• Relay Output: Presence Relay/Fault Relay
• Voltage tolerance : AC+10% / -15%
• Voltage tolerance : DC±15%
• Device Channel: Single /Double
• Operating temperature: 40℃ to +70℃ (-111℉ to +158℉)
• Sensitivity : 4 levels adjustable
• Relative Humidity: <95%
• Application: open gate, match with barrier gate, gate opener etc.
