TMT Global RG59 75 Ohm Copper-Braid Coaxial Cable, single slim RG59 coax, central copper conductor, white dielectric and visible woven copper-braid shield, black outer jacket, no auxiliary conductors.

RG59 75 Ohm Copper-Braid Coaxial Cable

KEY FEATURES

  • RG59 controlled construction
  • 75 Ω nominal impedance family
  • 20 AWG bare copper centre conductor
  • 95% braid class screening construction
  • 305 m standard package
Chat with Sales
AWG20 awg
BrandTMT Global
Jacket TypePVC, LSZH, PE Outdoor
ColourBlack, White
Length305 m
CONDUCTORBare Copper

Supplied in Oman by Khan Cables from our Muscat office and showroom in Ruwi, for projects in Muscat and across the Sultanate. Request a quote

Full specifications & datasheet: tmtglobal.co.uk →

View / Print DatasheetContact Sales
Description

TMT Global RG59 75 Ohm Copper-Braid Coaxial Cable Series

TMT Global RG59 75 Ohm Copper-Braid Coaxial Cable is a controlled standalone coaxial-cable family for professional ELV, video and RF installations. Classic RG59 analogue-video / CCTV construction with a 20 AWG centre conductor and braid screen. This reuses the existing RG59 product position rather than creating a duplicate generic coax page. Jacket and colour are exact searchable Series ordering variants; the centre-conductor and shield construction are fixed by the family.

KEY FEATURES

  • RG59 controlled construction
  • 75 Ω nominal impedance family
  • 20 AWG bare copper centre conductor
  • 95% braid class screening construction
  • 305 m standard package

APPLICATIONS

  • Analogue CCTV video
  • Baseband video
  • Security video links
