Green Color Cat6 Network Cable 23awg 4 twisted pair U Utp 305m

ELV Cables Green Color Cat6 Network Cable

Unmatched Performance for Your Networking Needs

Experience lightning-fast internet speeds with our Cat6 Network Cable. This high-quality cable features a 23 American Wire Gauge (AWG) construction, ensuring minimal attenuation and maximum data throughput. Ideal for streaming, gaming, or any high-bandwidth application, the Cat6 Network Cable provides a reliable connection to keep your devices online and performing at their best.Green Color Cat6 Network Cable

Robust Design to Withstand the Test of Time

Our 305-meter long Cat6 Network Cable is built with 4 twisted pairs and unshielded, twisted-pair (U/UTP) technology, which helps to reduce interference from external sources. This durable design makes it ideal for both residential and commercial environments. Whether you’re setting up a home office or outfitting a business, this cable ensures a stable and efficient network connection, allowing you to connect multiple devices without compromising performance.

Vibrant Green Color for Easy Identification

The vibrant green color of our Cat6 Network Cable adds a touch of style while providing practical benefits. Its distinctive appearance makes it easy to identify among other cables, which can simplify installations and maintenance. Plus, with its high-performance capabilities and robust construction, this cable is not only visually appealing but also highly functional, making it a perfect choice for both tech enthusiasts and casual users alike.

Invest in the Cat6 Network Cable for a seamless internet experience. This cable combines superior technology, durability, and an attractive design, making it the ideal solution for all your networking needs.

PHYSICAL AND MECHANICAL PROPERTIES

Basic Conductor: 23AWG TMT Copper
Insulation: HDPE
Number of insulated conductors: 8 twisted in 4 pairs
Color Code of Pairs: Blue x White/Blue, Orange x White/Orange, Green x White/Green, Brown x White/Brown
Outer Jacket: LSZH
Standard Jacket Color: Black /Grey/Blue/Orange/ Green/White/Aqua/ Yellows/Violet/Red
Standard Surface Marking: Includes TMT Global P/N, cable description, Meter mark and Model Number
Pulling force: 100 N MAX
Short Term Bend Radius: 6xOD (Mm)
Storage Temperature: -20 To +80C
Temperature operating range: -20 to +60C
Installation temperature range: 0 to +50C
Flame Test: IEC 60332-1

ELECTRICAL SPECIFICATIONS

• Characteristic Impedance: 100―6 Ohm @ 1-100 MHz
• DC Resistance: 93 Ohm/Km max.
• Resistance unbalance: 2% max.
• Mutual Capacitance: 5.6 nF/100m Max. @ 1 KHz
• Cap Unbalance (wire to ground): 1500 pF/Km max. @ 1 KHz.
• Voltage rating: 72 Vdc max.
• Dielectric strength: 1500 Volts/1 minute min rms
• Velocity of Propagation (NVP): 67-69%
• Insulation Resistance: 5000 MOhm•m min. @ 500 Vdc
• Coupling attenuation: IEC 61156-5 TYPE III
